0.96 INCH OLED LCD SCREEN I2C 128X64
2.25 د.ك
An OLED screen has no background color, instead, colors
the letters giving you a better view of the screen than the normal LCD screens.
In stock
Description
0.96 inch Oled Screen I2C
An OLED screen has no background color, instead, colors
the letters giving you a better view of the screen than the normal LCD screens.
Voltage: 3.3V – 5V
Viewing angle: 160 °
Working temperature: -30 ° – 80 °
Resolution: 128×64 pixels
Controller: SSD1306
Energy consumption: 0.04watt when all pixels are in use
Background color: Black
Module size: 27 x 27 x 4.1 mm
Dimension display: 26.00 x 15.00mm
The communication finds place through I2C
GND: Ground / Min / Earth
VCC: 3.3V or 5V
SCL: I2C SCL Clock signal
SDA: I2C SDA Data Signal
