HC-06 wireless Bluetooth

-14%

HC-06 wireless Bluetooth

3.50 KD 3.00 KD

SKU: EIT-WRL-007

9 in stock

  • Description
  • Reviews (0)
  • Product Specification

Description

The HC-06 is a slave Bluetooth 2.0+EDR serial (UART) pass-through module. It can easily pair with a master Bluetooth device, but cannot pair with another slave device.

It can be connected to the serial pins on your Arduino or other dev board and serve as a wireless serial link, all without having to do anything except connect power, ground, Tx, and Rx. Once powered, the module automatically starts broadcasting its ID waiting for a master Bluetooth device to pair with it.

The module has an on-board voltage regulator which allows you to power the module with supply voltages of 3.6V to 6V.

With a logic level of 3.3V you can directly connect this module to a Raspberry Pi but we recommend using a logic level converter when connecting it to 5V logic devices such as most Arduino boards.



Reviews

There are no reviews yet.


Be the first to review “HC-06 wireless Bluetooth”

  • Bluetooth Serial Transceiver Module with baseboard
  • Works with any USB Bluetooth adapters
  • Easy to use and completely encapsulated
  • This module includes key interface and state interface compared with Smart Bluetooth Module Baseboard
  • The Bluetooth Module Baseboard can be compatible with master mode, slave mode and both master-slave mode
  • Works for Bluetooth TTL transceiver module which allows your target device to both send or receive the TTL data
  • The key interface on the baseboard is the master mode button and can be controlled by high level from external MCU, then this module will search again automatically
